Summary
|
|||||
|---|---|---|---|---|---|
|
|
|||||
|
WHAT’S IN THE BOX
|
External Microphone
GPS Antenna Power Supply Leads Steering Remote Control cable USB Extension Cable(Type-C) |
||||
|
Size & Weight
|
|||||
|
DIMENSIONS (W X H X D)
|
178 x 100 x 132 mm
|
||||
|
WEIGHT
|
1.0 kg
|
||||
|
General Features
|
|||||
|
EQUALIZER
|
14-band Equalizer
|
||||
|
FIRMWARE UPGRADABILITY
|
Yes
|
||||
|
OUTPUT POWER
|
55W x4
|
||||
|
PRE OUT
|
3 Pre (Front LR / Rear LR / Sub x 1)
|
||||
|
REAR VIEW CAMERA IN
|
Rear
|
||||
|
TIME ALIGNMENT
|
Yes
|
||||
|
USB
|
Yes (Type-C x 1, REAR)
|
||||
|
Tuner Features
|
|||||
|
AUTO MEMORY
|
BTM
|
||||
|
PRESET
|
FM18/AM12
|
||||
|
RDS / EON
|
Yes (RBDS)
|
||||
|
Bluetooth® Profile
|
|||||
|
A2DP
|
Yes (1.3.1)
|
||||
|
AVRCP
|
Yes (1.6.1)
|
||||
|
HFP
|
Yes (1.7.1)
|
||||
|
PBAP
|
Yes (1.1)
|
||||
|
Bluetooth® Feature
|
|||||
|
ALPHABETICAL PHONEBOOK SORTING
|
Yes
|
||||
|
BATTERY REMINDER
|
Yes
|
||||
|
CALL VOLUME LEVEL CONTROL
|
Yes
|
||||
|
EXTERNAL MICROPHONE
|
Supplied
|
||||
|
LAST DIALED CALL
|
Yes(select from the dialed call history)
|
||||
|
PHONEBOOK ACCESS VIA PBAP
|
Yes
|
||||
|
RECENT CALLS (# OF)
|
Yes
|
||||
|
RING VOLUME LEVEL CONTROL
|
Yes
|
||||
|
SIGNAL STRENGTH INDICATION
|
Yes
|
||||
|
SPEED DIAL
|
Yes (6 memories)
|
||||
|
Bluetooth® Audio Feature
|
|||||
|
AUDIO CODEC (BLUETOOTH AUDIO)
|
SBC/AAC/LDAC
|
||||
|
AUDIO LEVEL ADJUSTMENT
|
Yes (-6dB to +6dB)
|
||||
|
CUE / REV
|
Yes
|
||||
|
META DATA INDICATION
|
Yes
|
||||
|
PAUSE (BLUETOOTH AUDIO)
|
Yes
|
||||
|
REPEAT CONTROL (AUDIO DEVICE SIDE)
|
Yes
|
||||
|
SHUFFLE CONTROL (AUDIO DEVICE SIDE)
|
Yes
|
||||
|
TRACK +/-
|
Yes
|
||||
|
Panel Design
|
|||||
|
KEY ILLUMINATION
|
Yes (White)
|
||||
|
Monitor(AVC)
|
|||||
|
BRIGHTNESS
|
Typ: 600 cd/m2
|
||||
|
DIMMER
|
Auto/Manual select
|
||||
|
LCD TYPE
|
Transmissive, TN Type
|
||||
|
RESOLUTION (DOT)
|
800 x 480
|
||||
|
SCREEN ASPECT
|
16 : 9
|
||||
|
SCREEN DIAGONAL (INCH / CM)
|
6.95 inches / 17.6 cm
|
||||
|
Display Panel
|
|||||
|
DIMMER ADJUST
|
Yes
|
||||
|
KEY ILLUMINATION INITIAL
|
White
|
||||
|
User Interface
|
|||||
|
PARKING CONTROL
|
Yes
|
||||
|
PARKING LINE ADJUST
|
Yes
|
||||
|
REAR VIEW CAMERA-IN MARKER SETTING
|
Yes
|
||||
|
TOUCH PANEL
|
Resistive
|
||||
|
USB Mass Storage Device Control Feature
|
|||||
|
USB DEVICE CONTROL (AUDIO CODEC)
|
MP3/WMA/WAV/AAC/FLAC/ALAC/DSF/DSDIFF
|
||||
|
USB DEVICE CONTROL (AUDIO PLAYABLE FILE EXTENSION)
|
.mp3/.wma/.wav/.m4a/.mp4/.flac/.m4a/.mp4/.dsf/.dff
|
||||
|
USB DEVICE CONTROL (PAUSE)
|
Yes
|
||||
|
USB DEVICE CONTROL (REPEAT)
|
TRACK/FOLDER/DRIVE
|
||||
|
USB DEVICE CONTROL (RESUME PLAY)
|
Yes
|
||||
|
USB DEVICE CONTROL (SHUFFLE)
|
OFF/FOLDER/DEVICE
|
||||
|
Multi-Language
|
|||||
|
CAUTION
|
English/Spanish/French/German/Italian/Russian/Portuguese/Simplified Chinese/Traditional Chinese/Dutch
|
||||
|
MENU
|
English/Spanish/French/German/Italian/Russian/Portuguese/Simplified Chinese/Traditional Chinese/Dutch
|
||||
|
Connectivity
|
|||||
|
BLUETOOTH®
|
Yes
|
||||
